| Specification | |||||
| Isolation | |||||
| Tension | Scope | Resolution | Accuracy | Test current | Current per c.s.. |
| 125V (0% ~ +10) | 0.125~4000MΩ | 0.001MΩ | ±(2%+10) | 1mA@load 125kΩ | ≤1mA |
| 250V (0% ~ +10) | 0.250~4000MΩ | 0.001MΩ | ±(2%+10) | 1mA@load 250kΩ | ≤1mA |
| 500V (0% ~ +10) | 0.500~4000MΩ | 0.001MΩ | ±(2%+10) | 1mA@load 500kΩ | ≤1mA |
| 1000V (0% ~ +10) | 1.000~4000MΩ | 0.001MΩ | ±(3%+10) | 1mA@load 1MΩ | ≤1mA |
| Low resistance | |||||
| Scope | Resolution | Accuracy | Max. U in open circuit | Protection is rushing. | |
| 4.000Oh | 0.001Oh | ±(1.5%+30) | 5.8V | 250Vrms | |
| 40.00Oh | 0.01Oh | ±(1.5%+3) | |||
| 400.0Oh | 0.1Oh | ||||
| Audible circuit indication (Continuity Beeper) | |||||
| Scope | Resolution | Accuracy | Max. U in open circuit | Protection is rushing. | |
| Chain(Continuity) | 0.01Oh | Съпротивление≤35Ω | 5.0V±1VDC | 250Vrms | |
| Current per c.s.. | ≥200mA | ||||
| Loop resistance | |||||
| L-PE (High current) | |||||
| Scope (Oh) | Resolution (Oh) | Accuracy | |||
| 0.00~999 | 0.01 | ±(4% +6 digits) | |||
| L-PE(without the involvement of DTZ): Measuring current:15mA / voltage range: 195V a.c.~260V a.c.(56,60Hz) | |||||
| Scope (Oh) | Resolution (Oh) | Accuracy | |||
| 0.00~999 | 0.01 | ±(5% +6 digits) | |||
| L-N: Measuring current:2.0A / voltage range:195V a.c.~260V a.c.(56,60Hz) | |||||
| Scope (Oh) | Resolution (Oh) | Accuracy | |||
| 0.00~999 | 0.01 | ±(4% +4 digits) | |||
| RCD test | |||||
| Test flow | Accuracy | ||||
| x1/2, x1, x2, x5 | 1.5%~ -9% | ||||
| Voltage and frequency | |||||
| Measuring range (V)/ AC-DC | Resolution (Oh) | Accuracy | |||
| 80-500V/(45-400Hz) | 1V | ±(2% +2 digits) | |||
Multifunctional tester for electrical installations DT6650
Multifunctional tester for electrical installations DT6650
6 finfunctions (Insulation testing,accident, contour, low resistance , earth resistance , tension)
- 6 finfunctions (Insulation testing,accident, contour, low resistance , earth resistance , tension)
- 5″ TFT full color display (320×240 pixels)
- Help menu , depicting the wiring diagrams for each of the tests
- SD memory to store the results
- Date and time recording for all tests
- Built-in Bluetooth for connecting to Android and iOS devices
- PC connection software
- IP 65
- TV out ( PAL or NTSC ) for presentations to the client
- Fast and accurate circuit test without the involvement of DTZ
- Pass / Fail indication for DTZ test
- Probe button to start the test
- Electronic protection against wrong connection
- Rapid high current loop test
