Multimeter DT951
True RMS Multimeter DT951
- Built-in powerful LED illuminator
- Bleutooth 4.0 for connection with android devices(model BT)
- TrueRMS measurement
- ACV, ACV+DCV, DCV measurement and low impedance mode (Lo Z) to eliminate the "ghost voltages" effect
- 4000 LCD display
- Analogs Bargraf
- Data-Hold, Min, Max,
- Circuit and diode test
- Degree of protection IP67
- Reinforced rubberized double molded case
- Run-out test – 2m
- Съответствие с безопасносттаEN61010-1 CAT III 600V
Technical information
Function scopes точност 951/951ВТ
DC Voltage(V) 400mV/4V/40V/400V/600V ±(0.8%+2) ±(0.8%+1)
AC Voltage(V) 4V/40V/400V/600V ±(0.8%+10) ±(0.8%+10)
DC current (A) 4A/10A ±(1.0%+3) ±(0.5%+10)
AC Current (A) 4A/10A ±(1.2%+3) ±(0.8%+3)
Resistance. (Oh) 400Ω/4KΩ/40KΩ/400KΩ/4MΩ/40MΩ ±(1.2%+5) ±(0.8%+10)
Capacity (F) 40nF/400nF/4μF/40μF/400μF/4000μF ±(3.0%+5) ±(3.0%+10)
Frequency (Hz) 10Hz-10KHz ±(0.1%+5) ±(0.1%+5) ±(0.01%+5)
Pace (ºC) -20ºC~760ºC ±(1.2%+3ºC) ±(1.0%+3ºC)
Diode test yes
Верига да
Bluetooth 951- не /951ВТ – да
Размери HxWxD): 150mm x 65mm x 38mm Тегло: 188g
